| Camera |
IPC6828EL-X42-W-VH1 |
| Sensor |
1/1.8" CMOS |
| Min. Illumination |
Colour: 0.0005 Lux (F1.2, AGC ON) |
| 0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| WDR |
120 dB |
| S/N |
>56 dB |
| Lens |
| Focal Length |
6.0~252mm |
| Optical Zoom |
42X |
| Digital Zoom |
16X |
| Iris |
F1.2 to F4.6 |
| Field of View (H) |
57.96° ~ 2.15° |
| Field of View (V) |
34.61° ~ 1.21° |
| Field of View (D) |
71.30° ~ 2.54° |
| DORI |
| DORI Distance (Detect) |
107.2 m ~ 3330.6 m (351.8 ft ~ 10927.2 ft) |
| DORI Distance (Observe) |
42.9 m ~ 1332.2 m (140.7 ft ~ 4370.9 ft) |
| DORI Distance (Recognize) |
21.4 m ~ 666.1 m (70.4 ft ~ 2185.4 ft) |
| DORI Distance (Identify) |
10.7 m ~ 333.1 m (35.2 ft ~ 1092.7 ft) |
| Video |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| Frame Rate |
Main Stream: 8MP (3840*2160), Max 30fps |
| Sub Stream: 2MP (1920*1080), Max 30fps |
| Third Stream: D1 (720*576), Max 30fps |
| Video Bit Rate |
128 Kbps to 16 Mbps |
| U-code |
Support |
| ROI |
Support |
| Video Stream |
Triple streams |
| Privacy Mask |
24 areas, up to 8 areas per scene |
| OSD |
Up to 10 OSDs |
| Events |
| Basic Detection |
Motion detection, Ultra motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind |
| General Function |
Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output |
| Audio |
| Audio Compression |
G.711U, G.711A |
| Audio Bitrate |
128 Kbps |
| Two-way Audio |
Support |
| Suppression |
Support |
| Sampling Rate |
16 kHz |
| Storage |
| Edge Storage |
Micro SD, up to 512 GB |
| Network Storage |
ANR, NAS (NFS) |
| Network |
| User/Host |
Up to 32 users. 3 user levels: administrator, common user and operator |
| Protocols |
SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
| Security |
Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, TLS 1.3, WSSE and Digest Authentication for ONVIF |
| Client |
EZStation, UNV-Link, UNV-Link Pro |
| Web Browser |
Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
| Intelligent |
| Auto Tracking |
Support, target filtering: human, non-motor vehicle and vehicle |
| Multi-target Detection |
Support |
| Smart Intrusion Prevention |
Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| People Counting |
Support people flow counting and crowd density monitoring |
| PTZ |
| Route Patrol |
16 patrols, up to 32 actions for each patrol |
| Recorded Patrol |
16 patrols, up to 128 actions for each patrol |
| Number of Presets |
1024 |
| Preset Image Freeze |
Support |
| Preset Patrol |
16 patrols, up to 64 presets for each patrol |
| Patrol Stay Time |
15 s to 1800 s |
| Home Position |
Support |
| Pan Range |
360° (endless) |
| Pan Speed |
0.1°/s ~ 180°/s |
| Tilt Range |
–15° ~ 90° (auto flip) |
| Tilt Speed |
0.1°/s ~ 180°/s |
| Image |
| White Balance |
Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Digital Noise Reduction |
2D/3D DNR |
| Flip |
Normal, Flip vertical, Flip horizontal, 180° |
| HLC |
Support |
| BLC |
Support |
| Defog |
Digital defog, Optical defog |
| EIS |
Support |
| Image Stabilization |
EIS (Gyroscope) |
| Interface |
| Audio I/O |
1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
| Alarm I/O |
07.თებ |
| Serial Port |
1 * RS485 |
| Network |
1 × RJ45 10 M/100 M Base-TX Ethernet |
| Video Output |
1 BNC (for debugging) |
| Illuminator |
| Illumination Distance (IR) |
500m |
| IR On/Off Control |
Auto/Manual |
| Wavelength |
850 nm |
| Certification |
| EMC |
CE-EMC (EN 55032: 2015+ A11: 2020; EN IEC 61000-3-2: 2019; EN 61000-3-3: 2013+ A: 2019; EN 55035: 2017+ A11: 2020) |
| Safety |
CE LVD (EN IEC 62368-1: 2020+ A11: 2020) |
| Environment |
CE-ROHS (2011/65/EU;(EU)2015/863) |
| Protection |
IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
| General |
| Power |
AC24V ± 25%, DC24V ± 25%, PoE (IEEE802.3bt) |
| Power Consumption |
Max 67 W |
| Power Interface |
Wires with cold-pressed terminal |
| Dimensions |
Ø 226.7 x 440.3 mm (Ø 8.93" x 17.33") (Ø x H) |
| Weight |
6.9 kg (15.21 lb) |
| Working Environment |
-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Storage Environment |
-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection |
6 KV |
| Reset Button |
Support |
| Heater |
Support |
